Description:
There are three Gateway models with VoxStack series 3G Gateway, the VS-GW1202 series, VS-GW1600 series and the VS-GW2120 series. The Modular Design 3G Gateways are ranging from 4 up to 44 3G/UMTS channels, developed for interconnecting a wide selection of codecs, including G.711A, G.711U, G.729, G.722, G.723, G.726 & GSM. With 3G connection to VoIP gateway,it can quickly reduce telecommunication expenses and maximize cost-savings. With the unique design of the VoxStack Gateway, it can support hot-swap for both SIM cards and 3G gateway modules. Users can simply add or remove the modules for hardware expansion or exchange. Each 3G gateway module runs an independent asterisk system inside.
The VoxStack gateway designs with a Lan Switch board that provides stackability on the hardware upgrade. It supports SMS messages sending and receiving and group sending and SMS to email. The 3G Gateways use standard SIP protocol and compatible with Leading IMS/NGN platform, IPPBX and SIP servers, support most of the VoIP operating platforms such as Asterisk, Elastix, 3CX, FreeSWITCH ,Broadsoft etc.
Technical Specifications:
4/8/12/16/20 3G/UMTS Channels
1 SIM card per 3G/UMTS channel
2 10/100M LAN Interface
Storage temperature range: -20~70℃
Operation temperature range: 0~40℃
Operation humidity range: 10%~90% non-condensing
Power source: 1U ATX power souce,100-240V/1-2A
Max Power Consumption: 46W
Dimension: 44cm × 4.5cm × 30cm
Weight:
VS-GW1600：3682g
VS-GWM400W：251g
Software & Platform:
Linux
Features
Simple and convenient configuration via Web GUI
Support http / https / SSH
Basic security strategy(white/black list, security rules)
Optional GSM Voice Codec
Codecs support: G.711A, G.711U, G.729, G.723.1, G.722, G.726, GSM
Quad-Band
900/2100MHz@UMTS, 900/1800MHz@GSM (UC15-E)
850/1900MHz@UMTS, 850/900/1800/1900MHz@GSM (UC15-A)
85 0/2100MHz@UMTS, 850/900/1800/1900MHz@GSM (UC15-T)
Support diverse SIP, IAX2 protocols
SIP(RFC3261) compliance
Multipe SIP/IAX2 Registratio models: None,server, client
DTMF Signaling support: RFC2833, Inband, SIPINFO
Real Open API Protocol(based on Asterisk)
Support static IP and DHCP
Call Duration Limit
CLIR(Call Line Identification Restriction)
Call Waiting
Call Forwarding (unconditional, no reply, busy, not reachable)
SMSC/SMS/USSD
SMS bulk transceiver, SMS automatically resend, Sent to Email
Support HTTP SMS interface
SMS Forwarding
USSD transceiver
SMS remotely controlling gateway
IMEI number automatically modify
PIN identification
Mobile number portability (MNP)
Flexible routing settings & unlimited routing rules
Support DISA
Extensible Automatic Callback and Speed Dial
Customizable IVR
CDR(More than 200,000 Lines CDRs Storage Locally)
Support configuration files backup and upload
Support for custom scripts, dialplans
Least Cost Routing(LCR),according to Time, Port, Calling Number
Independent System for Each Module
Affordable Price with Superior Performance
Hot-swap Design for both Sim cards and Modules
Compatible with sip server, such as: Asterisk, Elastix, 3CX, FreeSWITCH, etc
Available for OEM
3-Month « »No Questions Asked » » Return Policy
One Year Warranty
